Plastic Collapsible Container with Base Pallet

317-960-5813

Write a Review
SKU:
FGS-0013
The pallet and collapsible container are designed for washdown applications and the materials used are all FDA compliant.

Plastic Collapsible Container with Base Pallet Specs

Exterior Dimensions: 48” long by 42” wide by 46.9” high
Interior Dimensions: 46” long by 40” wide by 41.3” high
Collapsed Height: 9.1” (stackable)
Weight: 130 lbs
Rackable Load Capacity: 2,000 lbs
Dynamic Load Capacity: 5,000 lbs
Container Materials of Construction: Walls: Polypropylene Skins with a closed cell Polyethylene foam core, Aluminum channel edges
Fork Pocket Entry: 4-Way: 48" Side or 42" Side
Fork Pocket Openings: 48” Side: 14.42" x 3.68", 42” Side: 12.32"x 3.68"
Options: Barcode, RFID, and IoT tag options available
Customization: Custom sizes and load capacities available

My default content

Request A Quote
Have Questions?
Call 317.960.5813
View Gallery of Printable Images

Industry
Applications:

  • General Warehouse

    General
    Warehouse

  • Food and Beverage

    Food &
    Beverage

  • Pharmaceutical Industry

    Pharmaceutical
    Industry

  • Automated Facilities

    Automated
    Facilities

  • General Construction

    General
    Construction

Engineered with Versatility and Strength in Mind

The Artistic Composite Pallet's team takes great pride in providing a robust product to meet your needs.

Our plastic collapsible container is attached to a standard block pallet for easy material handling. The four walls of the container are erected or collapsed in sequence. At the top of each container wall is a spring latch to securely attach to the adjacent wall. Two of the walls contain a removable panel to allow easier operator loading or unloading of product. The pallet and collapsible container are designed for washdown applications and the materials used are all FDA compliant. The container can be erected and collapsed by either human operators or a robot.




Our Washdown Plastic Pallets are Tough and Built to Last

In automated closed loop systems, our pallets should last as long as the automation equipment. For open loop picking and truck transport, a typical useful life span of 50 trips. Artistic Composite Pallet continues to be the pallet of choice for many industries requiring a clean environment. High sanitation areas for food, beverage, or pharmaceuticals must eliminate any possible contamination sources. Our pallets are washdown capable which eliminates the need to fumigate or heat treat like the wood pallet.

The Artistic Difference

  • Superior Strength and Durability

    Superior Strength & Durability

    Our pallets meet the GMA standard while exceeding ISO and ASTM standards. Rated at a 2,800 lbs. rackable load, the low pallet weight and minimal dimensional deflection is a great match for automated systems.

  • Safety First

    Safety First

    Our pallets are splinter and nail-free which not only protects your employees but also your products stacked on our pallets.

  • Automated Systems

    Automated Systems

    We are experts in material handling systems integration and are compatible with your automated material handling equipment such as pallet conveyors, pallet dispensers, AS/RS, Pallet Shuttle Systems, and robotic palletizers.

  • Cost Savings

    Cost Savings

    Our composite pallets offer the most competitive life cycle cost while providing all the benefits of a more expensive plastic or aluminum pallet.

  • Cleanliness

    Cleanliness

    Washdown capability means our pallets are pest, fungus, and bacteria free for industries that need to meet the FDA cleanliness standards.

  • Sustainable

    Sustainable

    Artistic Composite Pallets is committed to protecting the environment and is using materials that enable the pallets to be recycled and reused into new pallets. This reduces the use of natural resources such as wood and required landfills.

  • Unlimited Industry Applications

    Unlimited Industry Applications

    Ideal for closed loop supply chain logistics; Pharmaceuticals, Food, Beverage, Building Construction Products, and Automated Rack Systems just to name a few.
